View In:   ArcGIS Online Map Viewer

Name: Drainage Basins

Display Field: SUB_BASIN_ID

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This data was collected by and maintaned by </SPAN><SPAN>Department of Public Works, Division of Environmental Storm Water Management. This dataset identifies more specific areas than that of the Major Watersheds layer. The data identifies the boundaries of the nautral drainage area for smaller specified areas whereas the Major Watershed is a large scale drainage area. </SPAN></P></DIV></DIV></DIV>

Copyright Text: Data was created and maintanined by the Department of Public Works, Division of Environmental Storm Water Management.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 1.2120147885785565E7
YMin: 3466101.2419634014
XMax: 1.2162488311402753E7
YMax: 3519674.7120476067
Spatial Reference: 102747  (2284)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [199, 224, 252, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• SUB_BASIN_ID ( type: esriFieldTypeString, alias: SUB_BASIN_ID, editable: true, nullable: false, length: 12, defaultValue: null, modelName: Sub_Basin_ID )
• C_FACTOR ( type: esriFieldTypeDouble, alias: C_FACTOR, editable: true, nullable: true, defaultValue: null, modelName: C_Factor )
• TIME_OF_CONCENTRATION ( type: esriFieldTypeDouble, alias: TIME_OF_CONCENTRATION, editable: true, nullable: true, defaultValue: null, modelName: Time_of_Concentration )
• MAJOR_WATERSHED ( type: esriFieldTypeString, alias: MAJOR_WATERSHED, editable: true, nullable: true, length: 2, defaultValue: null, modelName: Major_Watershed , Coded Values: [07: Broad Creek] , [09: Eastern Elizabeth River] , [08: Elizabeth River] , ...6 more... )
• CALCULATED_AREA_ACRE ( type: esriFieldTypeDouble, alias: CALCULATED_AREA_ACRE, editable: true, nullable: true, defaultValue: null, modelName: Calculated_Area_Acre )
• VERIFIED_BY ( type: esriFieldTypeString, alias: VERIFIED_BY, editable: true, nullable: true, length: 12, defaultValue: null, modelName: Verified_By , Coded Values: [CN: CLARK NEXSEN] , [GIS: GIS USER] , [KH: KIMLEY-HORN] , ...15 more... )
• COMMENTS ( type: esriFieldTypeString, alias: COMMENTS, editable: true, nullable: true, length: 254, defaultValue: null, modelName: Comments )
• created_user ( type: esriFieldTypeString, alias: created_user, editable: false, nullable: true, length: 255, defaultValue: null, modelName: created_user )
• created_date ( type: esriFieldTypeDate, alias: created_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: created_date )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, editable: false, nullable: true, length: 255, defaultValue: null, modelName: last_edited_user , Coded Values: [CN: CLARK NEXSEN] , [GIS: GIS USER] , [KH: KIMLEY-HORN] , ...15 more... )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: last_edited_date )
• Shape__Area ( type: esriFieldTypeDouble, alias: Shape.STArea(), editable: false, nullable: false, defaultValue: null, modelName: Shape.STArea() )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape.STLength(), editable: false, nullable: false, defaultValue: null, modelName: Shape.STLength() )

Templates:

• Name: Drainage Basins
  Description:
  Prototype:
  COMMENTS: null
  SUB_BASIN_ID:
  C_FACTOR: null
  TIME_OF_CONCENTRATION: null
  MAJOR_WATERSHED: null
  CALCULATED_AREA_ACRE: null
  VERIFIED_BY: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query

Sync Can Return Changes: false

Is Data Versioned: true

Supports Rollback On Failure: false

Supports ApplyEdits With Global Ids: false

Edit Fields Info:

• Creation Date Field: created_date
• Creator Field: created_user
• Edit Date Field: last_edited_date
• Editor Field: last_edited_user

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Attachments   Query Analytic   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
